· · International authoritative-certificate lighthouse factory & world-class manufacturing capability
· · Optimized key parts with ultra-high strength steel
· · Open hydraulic system & high configuration
· · SANY customized chassis & SANY DEUTZ Engine
· · Stable signal & precise control
· · A 10% increase in pumping efficiency
· · smoother flow, less blockage and meet long-time pumping need
· · Dual-purpose machine: quickly transform into a line pump
· · Various boom types & flexible working posture
· · Less site limitation, smaller footprint & wider placement range
· · Advanced fuel combustion & intelligent power matching technology
· · The best cost performance choice
· · Easy maintenance, cost-saving and time-saving
· · The industry-leading longest service life of wear parts
· · High configuration cab & exceptionally comfortable driving experience
· · Single-button operation design & optimized flow of the entire process
· · MachineLink+ & all in your control
· · 24/7 rapid troubleshooting & spare parts supply guaranteed
| Boom & Outrigger Specification | |
| Horizontal Reach | 51 m |
| Reach Depth | 36.6 m |
| Vertical Reach | 56 m |
| Chassis Specification | |
| Chassis Brand | SANY |
| Chassis Model | SYM5440THB1E (Euro Ⅴ） / SYM5440THB1C (Euro Ⅲ） |
| Overall Specification | |
| Empty Weight | 43500 kg |
| Height | 4000 mm |
| Length | 14150 mm |
| Width | 2550 mm |
| Pumping System Specification | |
| Output | 200/137 m³/h |
| Pressure | 8.3/12 MPa |
