· · International authoritative-certificate lighthouse factory & world-class manufacturing capability
· · Optimized key parts with ultra-high strength steel
· · Open hydraulic system & high configuration
· · SANY customized chassis & SANY DEUTZ Engine
· · Stable signal & precise control
· · A 10% increase in pumping efficiency
· · smoother flow, less blockage and meet long-time pumping need
· · Dual-purpose machine: quickly transform into a line pump
· · Various boom types & flexible working posture
· · Less site limitation, smaller footprint & wider placement range
· · Advanced fuel combustion & intelligent power matching technology
· · The best cost performance choice
· · Easy maintenance, cost-saving and time-saving
· · The industry-leading longest service life of wear parts
· · High configuration cab & exceptionally comfortable driving experience
· · Single-button operation design & optimized flow of the entire process
· · MachineLink+ & all in your control
· · 24/7 rapid troubleshooting & spare parts supply guaranteed
| Boom & Outrigger Specification | |
| Horizontal Reach | 37.7 m |
| Reach Depth | 27 m |
| Vertical Reach | 42.5 m |
| Chassis Specification | |
| Chassis Brand | SANY |
| Chassis Model | SYM5350THB1E |
| Overall Specification | |
| Empty Weight | 31500 kg |
| Height | 4000 mm |
| Length | 11700 mm |
| Width | 2550 mm |
| Pumping System Specification | |
| Output | 160/96 m3/h |
| Pressure | 7/12 MPa |
