Features
Premium Productivity· Powerful, robust and reliable powertrain & hydraulic components for long life in the most demanding applications. Selectable working modes match machine performance to the application, maximizing productivity
Super long service life· Through experience accumulation of 15 years, and by virtue of “three-in-one” design & test system for large excavators of SANY, the operating life is more than 15,000H under mining working condition.
Super high adaptability· Anti- corrosion coating, Independent extra-large radiator, High-capacity Multi-stage Filtration System.
Intelligent System· Operation interface upgrade, intelligent operation interface of fashion technology, simpler and more convenient.
Lower Fuel Consumption· Optimized positive flow hydraulics improve operating efficiency by up to 5% and fuel efficiency by up to 10%
Specs
| Arm Digging Force |
120 KN |
| Bucket Capacity |
1.3m³ |
| Bucket Digging Force |
175 KN |
| Carrier Wheel on Each Side |
2 |
| Engine Displacement |
6.373 L |
| Engine Model |
D06FRC |
| Engine Power |
147 kW |
| Fuel Tank |
475 L |
| Hydraulic Tank |
277 L |
| Operating Weight |
25.5 T |
| Radiator |
30.9 L |
| Standard Boom |
5.9 m |
| Standard Stick |
2.95 m |
| Thrust Wheel on Each Side |
9 |
