Features
Intelligent attachment matching· Brand-new attachment operating system, preset various accessory pressure/flow parameters, realize adjustable auxiliary pipeline flow and controllable operation speed, and meet the operation requirements of frequent accessory replacement for different customers and regions.
Safety Protection· Integrating the intelligent technology into the products and developing a hierarchical password management system are to create an intelligent and secure working platform for customers, and make the machine management more arbitrary and secure.
Energy efficiency improvement· The application of electronic control pump and new main valve, the electronic control technology of hydraulic pump adjusts power, and the action response speed is faster, and the overall operation efficiency is improved.
Safe and Comfortable Operating Environment· The newly-designed cab with much room and larger windows provides you with a wider view.Equipped with excellent sealing, the cab is free from dust, rain, and noise that effectively reduce the fatigue of operator.
Specs
| Arm Digging Force |
33 KN |
| Bucket Capacity |
0.25m³ |
| Bucket Digging Force |
45 KN |
| Carrier Wheel on Each Side |
1 |
| Engine Displacement |
3.3 L |
| Engine Model |
Yanmar 4TNV98C |
| Engine Power |
42.4 kW |
| Fuel Tank |
130 L |
| Hydraulic Tank |
85 L |
| Operating Weight |
6 T |
| Radiator |
10.4 L |
| Standard Boom |
3 m |
| Standard Stick |
1.7 m |
| Thrust Wheel on Each Side |
5 |
