Model | BM-80 | BM-80C |
WEIGHT | ||
Operating weight | 800 | 800 |
Static load(N/CM) | 58/63 | 59/64 |
SIZE | ||
Working Width(MM) | 680 | |
Overall length(MM) | 2500 | |
Machine height(MM) | 1140 | |
Width of wheel(MM) | 700 | |
Diameter of wheel(MM) | 500 | |
Tread(MM) | 1230 | |
DRIVE | ||
Engine manufacturer | HONDA | CHANGFA |
Engine model | GX390 | 180F |
Engine type | Gasoline,single cylinder,air cooling, four stroke | Diesel,single cylinder,air cooling,four stroke |
Output power(HP/KW) | 13/9.7 | 6.4/4.8 |
Ratating speed(rpm) | 3600 | 3600 |
Electrical equipment(V) | 12 | |
Drive mode | Variable displacement pump,stepless speed change, two drums | |
WALKING CHARACTERISTICS | ||
Speed(KM/H) | 0-3.5 | |
Theoretical climbing ability | 30% | |
BRAKE | ||
Working brake | Variable displacement pump | |
STEERING | ||
Steering mode | Hyaulic steering | |
Steering system | Steering support plate | |
EXCITATION SYSTEM | ||
Drive form | Mechanical transmission electromagnetic clutch | |
Vibration frequency(HZ) | 65 | |
Vibration amplitude(MM) | 0.5 | |
Exciting force(KN) | 20 | |
Capacity | ||
Hydraulic oil capacity | 6.5 | 3.5 |
Fuel capacity(L) | 28 | |
Water tank capacity | 30 |
